HW4: Violet’s Vending Venture

JMU Pizzeria

Image source: vecteezy

Learning Objectives

  • Implement a UML diagram for classes.
  • Implement method overloading in code.
  • Write a program that uses ArrayList for data storage.
  • Use enums to model fixed categories with associated values.
  • Apply exception handling to enforce data validation and system rules.

Overview

A JMU alum, Violet is starting a business with vending machines at different locations on Campus. She wants the business to be profitable, thus to plan she needs your help writing a Java program that simulates a vending machine interaction. The goal of the program is to calculate the profit made by each individual machine, as well as the total profit from all machines combined.

This vending machine sells multiple types of products, each with its own cost and selling price. The program should handle the logic to calculate profit for each item sold, then total the profits for the whole machine.

The program should then display the individual machine profits and also the total business profit.

The Classes to be Written

The following UML diagram shows all of the classes and relationships between them. Note that dependencies (weak relationships) are omitted from the diagram.

classDiagram
    direction TB

    class ProductType {
        <<enumeration>>
        +WATER#40;0.25, 1.00#41;
        +SODA#40;0.35, 1.50#41;
        +CANDY#40;0.40, 1.25#41;
        +CHIPS#40;0.70, 2.00#41;
        +COOKIES#40;0.85, 2.25#41;
        - cost : double
        - price : double
        -ProductType(cost: double, price: double)
        +getCost() double
        +getPrice() double
    }

    class Product {
        + ROUND_PRICE : int = 25$
        - type : ProductType
        - name : String
        - cost : double
        - price : double
        + Product(type: ProductType, name: String)
        + setCustomPrice(price: double)
        + getName() String
        + getType() ProductType
        + getPrice() double
        + getCost() double
        + toString() String
    }

    class Slot {
        + SLOT_SIZE: int = 10$
        - type : ProductType
        - products : ArrayList~Product~
        + Slot(type: ProductType)
        + load(product: Product, count: int) int throws IllegalArgumentException
        + nextProduct() Product
        + buyOne() Product
        + toString() String
     }

     class VendingMachine {
        - totalProfit : double$
        - machineProfit: double
        - slots: Slot[]

        + getTotalProfit() double$
        + resetTotalProfit()$
        + VendingMachine(types: ProductType[])
        + load(slotNum: int, count: int, product: Product)
        + nextProduct(slotNum: int) Product
        + buy(slotNum: int) boolean
        + buy(type: ProductType) boolean
        + getSlotCount() int
        + getMachineProfit() double
        + toString() String

    }

    class Simulator {
        - vmList: ArrayList~VendingMachine~
        + Simulator(vmList: ArrayList~VendingMachine~)
        + addVM(vm: VendingMachine)
        + simulate(pCount: int) double
    }

    Simulator --> VendingMachine : simulates
    VendingMachine *-- Slot : is made up of
    Product --o Slot : contains

    ProductType <-- Product : has a

    Slot --> ProductType : has a

    %% VendingMachine ..> Product : sells
    %% VendingMachine ..> ProductType : uses

Where to Start?

If you look at the UML diagram, you can see how certain classes depend on others. For example, Product depends on only ProductType, while Slot depends on both Product and ProductType.

Start by coding the class with the fewest dependencies – ProductType.

You will be writing three primary classes: Product, Slot and VendingMachine. The Simulator class will simulate user interaction with the vending machine, utilizing the functionality of all the core classes together. Finally, the ProductType enum will represent predefined categories of products, each associated with a default cost and price. It is used by the Product class to determine pricing and by other classes to enforce type consistency.

All the classes must be in the hw4 package. The getter (accessor) methods for all the classes must return the appropriate instance (attribute) variable values.

ProductType.java

The ProductType enumeration (more about enum📖) defines the fixed set of product categories available in the vending machine. Each product type is associated with two values:

  • cost : double – the amount it costs the vending machine company to stock the item.
  • price : double – the amount the customer is charged for the item.

This enum is used throughout the system to categorize products or apply default pricing.

Note that, although it is an enum, the ProductType enum must still have a constructor. The constructor has parameters of cost and price, and sets the corresponding attributes. This constructor should be private, or better, omit the visibility of your constructor like so:

public enum ProductType {
    ...
    ProductType(double cost, double price) {
        ...
    }
    ...
}

The Product Class

The Product class models an individual item type in a vending machine. Each product is associated with a ProductType and also has a name. The default cost and price values are based on the ProductType.

Some products may need a custom price, thus the setCustomPrice() method. Violet has said that she is unwilling to deal with anything but quarters, dollar bills, and debit cards so all prices are kept divisible by 25 cents. Costs to the vending machine company can be any penny value. All of the getter methods perform the expected operation.

Detailed Design Specifications

  1. Product(ProductType type, String name) This constructor takes the type and name as parameters and sets the instance variables appropriately.

  2. setCustomPrice() takes a custom price and sets it for the product instance. Price should be rounded to the next

  3. ROUND_PRICE cents above the amount given if the amount given is not already divisible by ROUND_PRICE.

Note: ROUND_PRICE represents the value in cents to which all prices should be rounded. If the price given is not greater than the associate cost, the price should be the next ROUND_PRICE- divisible-value that is greater than the cost.

Example

Let’s say we’re setting a custom price of $2.35, but the system only allows prices in multiples of 25 cents (like $2.00, $2.25, $2.50, etc.). Since $2.35 is not a multiple of $0.25, the system needs to round it up to the next closest allowed price.

  • $2.35 is between $2.25 and $2.50
  • The next allowed price (going upward) is $2.50

So, when you enter $2.35, the setCustomPrice() should convert it to $2.50 to match the required rounding rule.

  1. toString() method will return a String of the instance variables of the class exactly as shown below. Assuming an instance with type "CANDY", name "M&Ms", cost of $1.02, and a price of $1.25, toString() would return:

CANDY: M&Ms Cost: 1.02 Price: 1.25.
Note that both cost and price are represented with two significant digits as dollars would expect to be. Also, cost and cents are kept in pennies as an integer, so the toString method will need to transform the values into the right format.

The Slot Class

The Slot class models a slot in the vending machine. Slots are loaded from the rear, and purchases are removed from the front. This ensures that the items that have been in the machine the longest are sold before newly added items.

  • SLOT_SIZE: int = 10 - the maximum number of products that a slot in the vending machine can hold.

  • products: ArrayList<Product> - models the actual products that are in the slot. Removing the one at the front models buying one of the products in the slot and all of the others are moved forward similar to an actual vending machine.

Detailed Design Specifications

In addition to the specifications contained in the UML class diagram, this class must conform to the following specifications.

  1. Slot(ProductType type) The Slot() constructor creates an empty array list of products and sets the type.

  2. load(Product product, int count) checks if the given product’s ProductType matches the slot’s ProductType. Loads the slot with up to count products, without exceeding capacity. Use SLOT_SIZE as the default value to fill the slot completely. Return the number of products added accordingly. This method should throw an IllegalArgumentException with the message "Product type does not match slot product type" if the type of the product you are trying to load does not match the slot’s product type.

  3. nextProduct() returns a reference to the next product available for purchase, without actually removing it from the slot. If the slot is empty, this method will return null.

  4. buyOne() simulates the purchase of one item from the perspective of the slot. That means no money is dealt with here, rather the slot is checked to make sure there is product to buy and then one product is removed from the front of the ArrayList modeling the slot. If a product is successfully removed from the slot, it is returned, otherwise null is returned.

  5. toString() returns a String exactly like the one below for a slot with 6 M&M products. Items should start with the front slot and end with the rear slot.

    SlotCount: 6 of
    CANDY: M&Ms Cost: 1.02 Price: 1.25.
    CANDY: M&Ms Cost: 1.02 Price: 1.25.
    CANDY: M&Ms Cost: 1.02 Price: 1.25.
    CANDY: M&Ms Cost: 1.02 Price: 1.25.
    CANDY: M&Ms Cost: 1.02 Price: 1.25.
    CANDY: M&Ms Cost: 1.02 Price: 1.25.

Hint

Don’t forget to make use of other toString() methods.

The VendingMachine Class

The VendingMachine class is a simple vending machine. Exact change is required so it is assumed if someone is buying something they have inserted the right amount of money or have used a debit card. The getter methods return the appropriate instance variable (attribute) values.

  • totalProfit: double – this models the total profit for all of the VendingMachines together. It is the sum of the price of every product bought from all of the machines minus the sum of the cost of all the products ever put in all of the machines.

  • machineProfit: double – this models the long term profit for this particular machine. It is the sum of the price of every product bought from this machine minus the sum of the cost of all the products ever put in this machine.

  • slots: Slot[] – this array models the array of slots in the VendingMachine.

Detailed Design Specifications

In addition to the specifications contained in the UML class diagram, this class must conform to the following specifications.

  1. VendingMachine(ProductType[] types) Creates a new VendingMachine with one slot for each ProductType in the given array. Each slot is initialized using the corresponding ProductType at the same index. Thus, the number of slots equals the array length.

  2. load(int slotNum, int count, Product product) Loads the slot indicated by slotNum with product until it is full or until count is reached. Makes appropriate adjustments to machineProfit and totalProfit by subtracting costs from profit values.

    • Watch out! Recall that the load() method of the Slot class may throw an exception. You do not need to handle the exception here; instead, just use the throws keyword in the method signature to indicate that this method will “pass on” any exceptions to its caller.

  3. nextProduct(int slotNum) Returns a reference to the next available product in the indicated slot or null if the slot is empty.

  4. buy(int slotNum) Models buying one item from the slot number indicated. Makes appropriate adjustments to machineProfit and totalProfit by adding the price to the profit values. Returns false if there is no product to buy.

  5. buy(ProductType type) Models buying one item from the first slot that matches the indicated product type. Makes appropriate adjustments to machineProfit and totalProfit by adding the price to the profit values. Returns false if there is no product to buy.

  6. resetTotalProfit() This method resets the totalProfit static instance variable to zero. This is useful when testing to make sure that different method tests start out in a known state for the static variable so the final value can be computed without knowing the order of the test runs.

  7. getTotalProfit() This method is a simple getter for the static totalProfit variable, which must track the total profit accumulated across ALL instances of VendingMachine, not just this specific one.

  8. getSlotCount() Returns the number of slots in the vending machine. Note that, internally, the vending machine stores its slots in an array, where each slot can hold a specific product and its quantity. This method returns the length of that array.

  9. getMachineProfit() Returns the total profit earned by a single vending machine, calculated as the sum of profit for all sold products.

  10. toString() Returns a String representing the VendingMachine, each loaded slot, the machineProfit and totalProfit exactly as shown below for a 2-slots with different numbers of loaded products. VendingMachine filled with 7 Skittles in one slot and 5 Oreos in second, where nothing has been bought (so the profits are negative).

    Vending Machine
    SlotCount: 7 of
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    CANDY: Skittles Cost: 0.40 Price: 1.25.
    SlotCount: 5 of
    COOKIES: Oreos Cost: 0.85 Price: 2.25.
    COOKIES: Oreos Cost: 0.85 Price: 2.25.
    COOKIES: Oreos Cost: 0.85 Price: 2.25.
    COOKIES: Oreos Cost: 0.85 Price: 2.25.
    COOKIES: Oreos Cost: 0.85 Price: 2.25.
    Total Profit: -7.05 Machine Profit: -7.05.

Hint

Use the existing toString() methods.

The Simulator Class

The simulator will provide a means of simulating a small business of vending machines. The vending machines of the business are stored in an array list. Vending machines can be added to the list using the provided method to simulate the growth of a business. Simulation of the business “running” and selling product is done by simulating a specific number of products being bought from every slot of every vending machine in the business and returning the totalProfit of all of the vending machines in cents.

  • vmList: ArrayList – models the list of vending machines owned by the company

Detailed Design Specifications

  1. Simulator(ArrayList vmList) instantiates a Simulator.

  2. addVM(VendingMachine vm) adds the VendingMachine indicated by vm to the end of the list of vending machines owned by the company.

  3. simulate(int pCount) simulates buying pCount products from every slot of every VendingMachine owned by the company. Returns the totalProfit of all of the VendingMachines.

Submission

Part A: Canvas readiness quiz

Read the full Assignment. Don’t skip anything. Understanding the whole picture now will save you from headaches later. Then, complete readiness quiz of this assignment in Canvas.

Part B: Stub-out the Classes and Write the simple Enum ProductType

Awesome

You’re stepping right into the world of Test-Driven Development (TDD). 🙌🏽

Step 1: Get Started

  • Inside hws, make a new folder called hw4. This will be the home base for everything in this assignment.

Step 2: Write the simple Enum ProductType

  • Create an enum ProductType with constants like WATER, CANDY, etc.
  • Refer to the UML and notes to associate each constant with a cost and price.

Step 3: Stub-out Product class

  • Create the Product class stubs

Step 4: Stub-out Slot class

  • Create the Slot class stubs

Step 5: Stub-out VendingMachine class

  • Create the VendingMachine class stubs

Step 6: Stub-out the Simulator class

  • Create the Simulator class stubs

Step 7: Submission

  • Submit your enum ProductType.java and all stub files(Product.java, Slot.java, VendingMachine.java, and Simulator.java) to Gradescope.

Part C: Write the test classes

Step 1: Download provided tests

Step 2: Read and understand the tests in ProductTest.java and SimulatorTest.java.

Step 3: Write tests for Slot class

  • Write the test class for the Slot class, name it as SlotTest.java
  • For each method in Slot, write a corresponding test:1) Test expected outcomes; 2)Include edge cases (e.g. max and min, null values, etc.); and 3) Use assertEquals, assertTrue, etc., to verify behavior

Step 4: Write tests for VendingMachine class

  • Write the test class for the VendingMachine class, name it as VendingMachineTest.java

Step 5: Submission

  • Submit your tests files(SlotTest.java and VendingMachineTest.java) to Gradescope.

Part D: Implement all classes

Step 1: Implement and Test the Product Class

  • Before you implement the logic and run anything, grab a pencil and paper and manually calculate what the expected outputs of ProductTest should be. This will help you truly understand how the Product class is supposed to behave.
  • Now write the actual logic in your Product class methods based on what you’ve learned. Make it do what it’s supposed to do!
  • Run ProductTest. If any tests fail, dive into the relevant method(s) in Product.java and figure out what’s going wrong. Here is how to run tests in VSCode!
  • Fix the bug, run the test again, and keep iterating until all tests in ProductTest pass.

Step 2: Implement and Test the Slot Class

  • Start coding each method according to the design.
  • Run SlotTest and check the results.
  • If any test fails, inspect both your test logic and Slot class implementation to find the bug.
  • Tweak your code or tests as needed, then rerun everything until all tests pass and you’re confident it works.

Repeat similar steps for VendingMachine and Simulator

You must submit (using Gradescope): the Product class, the Slot class, the VendingMachine class and the Simulator class.

Grading

Your code will first be graded by Gradescope and then by the Professor. The grade you receive from Gradescope is the maximum grade that you can receive on the assignment

Gradescope Grading

Your code must compile (in Gradescope, this will be indicated in the section on “Does your code compile?”) and all class names and method signatures must comply with the specifications (in Gradescope, this will be indicated in the section on “Do your class names, method signatures, etc. comply with the specifications?”) for you to receive any points on this assignment. Gradescope will then grade your submission as follows:

Criterion Points Details
Conformance to the Style Guide (Style) 0 points (All or Nothing: Success Required on all parts)
Compilation 0 or 5 points (All or Nothing: Success Required on all parts)
Part A: Canvas readiness quiz 10 points (All or Nothing: Success Required)
Part B: Stubs and ProductType 20 points (Compilation Required 5 points, Partial Credit Possible on ProductType)
Part C: Runs your tests against our reference solution 10 points (Partial Credit Possible)
Part C: Passing Your Tests (SelfTests) 10 points (Partial Credit Possible)
Part D: Correctness (Official Tests) 50 points (Partial Credit Possible)

Questions to Think About

You don’t have to submit your answers to these questions, but you should try to answer them because they will help you determine whether or not you understand some of the important concepts covered in this assignment.

  1. How does using the ProductType enum improve the design of the Product class compared to using strings or integers?
  2. What is the benefit of separating the logic into multiple classes like Product, Slot, and VendingMachine instead of
  3. putting all code into one class?
  4. What rule should setCustomPrice() in Product enforce so that the assigned price always aligns with the ROUND_PRICE
  5. and stays consistent with system pricing rules?
  6. How can the load() method safely prevent loading an incorrect product type in a Slot?
  7. How do the buy() methods relate to machineProfit and totalProfit in VendingMachine?
  8. Could you reuse the VendingMachine class in a different project? Why and how or why not?
  9. When writing tests for Slot and VendingMachine, what helped you better understand how the classes were supposed to
  10. behave?
