Eclipse

Introduction

In this lab, you will explore Eclipse. If you already use the Eclipse editor, this lab may provide you with more information. If you are new to Eclipse, make sure to watch the videos in the Resources section below to get oriented to the vocabulary and layout of Eclipse.

All Eclipse applications are built as a project. If you choose to use Eclipse this semester, each lab and each PA that you complete will be in its own project and each project will have its own folder.

Resources

Dr. Piercy's A Brief Tour of Eclipse (~9 min) covers basic vocabulary and explains different areas in the Eclipse screen.
Norm Krumpe's Eclipse Tutorial (~3 min) covers additional information you'll need to complete this activity.

Part 1 - Hello World

  1. If you have not done so already, open Eclipse. At the "Workspace" prompt, fill in a location for your workspace. Note this will be where your java programs are stored.
  2. Choose the tutorials icon. (Pen and green check-mark).
  3. Choose "Create a Hello World application".
  4. Follow the steps in the tutorial. Be sure to see how the automatic syntax checking works by introducing some bugs. Also explore the autofill options (showing the list of available members of an object).

Part 2 - Coding in Eclipse

  1. Create a new Eclipse project named PointLab:
    File -> New -> Java Project
  2. Enter the Project Name - PointLab - then under Project Layout choose the option to use project folder as root for sources and class files. This will make zipping the files together to submit online easier.
  3. Click Finish and the project should show up on the left in the Package Explorer.
  4. Use Eclipse to create a new class that corresponds to the UML diagram below. To create the class choose File -> New -> Class . Use the Browse button to choose the project folder you just created above. Name the class. The other default values should be just fine. Don't worry about commenting the code just yet. We'll address that later on.

    The return value of the toString method should consist of an open-parenthesis followed by the x-coordinate, followed by a comma, then a space, then the y-coordinate followed by a close-parenthesis. For example: "(1.0, 2.0)".

    The equals method should return true if the two points have the same x position and y position.

  5. Once you have completed a syntactically correct Point class, move on to the next step.

Part 3 - Adding A .jar File

One standard mechanism for distributing Java code is through .jar files. A .jar file is a compressed archive that can hold any number of Java classes in either source or binary form (as .java files or as .class files). For some projects in this course you will be provided with .jar files containing support code.

  1. Create a new folder named "lib" in your Java project. Download the file PointCode.jar, into the newly-created folder. If the file does not show up in the Package Explorer on the left, refresh the diplay by selecting File -> Refresh and it should appear.
  2. Right click PointCode.jar and select Build Path -> Add to Build Path.
  3. There should now be a "Referenced Libraries" entry in your package explorer. Expanding that entry should allow you to inspect the details of the PointCode.jar archive. All classes included in that archive are now available within your project. In this case there is only one class: PointDisplay. It should be under the default package.

Part 4 - Importing and Running

  1. Download the file PointDemo.java to your Desktop, then drag it into the folder of your project where you stored your source code.
  2. Look over the PointDemo class to get a feel for what it should do. Run the code to confirm that everything is working as expected.

Part 5 - Checkstyle Eclipse Integration

Checkstyle is a development tool that makes it easy to test Java code against a particular coding standard. Our Web-CAT submission system will analyze your programming assignments using Checkstyle to verify that they conform to the CS159 style guide. It will be in your best interest to use Checkstyle off-line so that you can avoid wasting your limited submissions. Checkstyle can be run from the command line, but today we will try it out using an Eclipse plug-in.

  1. Navigate to the following web-page in a separate browser window or tab: http://eclipse-cs.sourceforge.net. Drag the blue "Install" button onto your Eclipse window and follow the instructions for installing the plugin.
  2. Download the following XML file to your Desktop: CS159s19_checkstyle.xml. This file contains a Checkstyle configuration that matches the CS159 style guide. This is exactly the same configuration that AutoLab will use to check your submissions.
  3. Configure the Checkstyle plugin to use the configuration file: Eclipse -> Preferences -> Checkstyle -> New. Select "External Configuration" as the Type and then select the file you downloaded in the previous step. Click "OK" and then set this configuration as the default by selecting this new file and then clicking Set as Default on the right.
  4. Unfortunately, Checkstyle needs to be explicitly enabled for each new Eclipse project. Right click your PointLab project in the "Package Explorer" tab and then select Properties -> Checkstyle. Click on the check-box labeled "Checkstyle active for this project".
  5. Once you have completed the previous step, navigate to your Point.java file, right-click in the editor window and select Checkstyle -> Check Code with Checkstyle. Many lines of code should now be marked in yellow. Each of these marked lines contains a violation of the style guidelines that would prevent you from successfully submitting a programming assignment. Clicking on the yellow magnifying glasses in the left margin will show you a description of the problem. We'll fix these problems in the next part of the lab.

Part 6 - Eclipse Auto-Formatting

One of Eclipse's handiest features is the ability to automatically handle low-level code formatting. This dramatically reduces the effort involved in producing consistently formatted (and thus more readable) code. This auto-formatting feature will also help you write code that conforms to the course coding standards.

  1. Download the file CS159s19_formatter.xml. This XML file contains the configuration information necessary for Eclipse to format your code in a way that is consistent with the CS159 coding standards.
  2. Configure Eclipse to use the file you just downloaded: Preferences -> Java -> Code Style -> Formatter -> Import.
  3. Once you have configured the auto-formatter you should be able to re-format your Point.java file by selecting the entire file (CTRL-A) and then pressing SHIFT-CTRL-F.
  4. Once you have auto-formatted your code (and saved it!), re-validate using Checkstyle. Hopefully, many of the flagged formatting errors should now be gone. Most of the remaining issues probably relate to missing Javadocs.
  5. Add appropriate Javadoc comments to your Point class. Eclipse will automatically generate a Javadoc template for any method. You can either type /**[ENTER] just above the method, or select the method and press SHIFT-ALT-J.
  6. Re-run Checkstyle, and address any remaining formatting issues.
  7. Note that a human-readable version of the style guidelines is available as CS159s19_StyleGuide.pdf

Part 7 - JUnit Integration in Eclipse

JUnit is a framework that automates testing by providing a standard format for tests and an easy way to execute them (see JUnit FAQ).  The JUnit site provides a wealth of useful information on JUnit and the host of JUnit-based products ( visit http://www.junit.org/). For most of the programming assignments and labs in this course, you will be required to test your own code using JUnit. We will talk more about testing before we require you to write your own JUnit tests, but today we will learn how to create a test class in Eclipse and use provided tests to test your code.

  1. Select File -> New -> Junit Test Case. Select "New JUnit Jupiter test" and name your class PointTest. If you were creating your own test class you would now click Next, and select the Point class to make stub testing methods. Instead click Finish.
  2. Now you should be able to copy the text only of the test class provided to you and paste it into this class. Make sure and download the test class into a text editor such as Atom or Notepad before copying it. DO NOT copy it from the webpage. PointTest.java
  3. To run JUnit tests, select Run -> RunAs -> JUnit Test. This will test your methods using PointTest.
  4. Finish debugging your Point class using the test cases provided.

Part 8 - Submitting Through AutoLab

  1. Navigate to http://autolab.cs.jmu.edu and log-in.
  2. Upload Point.java
  3. If your code fails any of the submission tests, make any necessary modifications and resubmit until there are no failures.
